Full Automatic PET& PP Bottle Blowing Machine (with extrusion）

This full automatic PET, PVC, and PP disposable plastic Bottle Blowing machine with extrusion is designed for efficient production of food-grade plastic Bottle . It supports multiple materials and delivers stable performance, precise forming, and high output with minimal labor.

Item No :
GYC-B2026-01
Order(MOQ) :
1 SET
Payment :
CONTACT
Product Origin :
CHINA
Color :
CUSTOMERMIZED
Shipping Port :
CHINA PORT
Lead Time :
35-45DAYS
Weight :
18TON

Inquiry now

product introduction

Automatic PET& PP&PVC Bottle Blowing Machine with extrusion. --PET.PS ,PVC different raw material .

TYPE	ITEM	UNIT	TECHINICAL DATA (L-BS514 1出2)
	Product material		PET
	最大容量Max volume of product	L	0.1-1.5L
	最大口径Neck diameter	mm	18-48
	产量 theoretical output	pcs/hr	1800-2000
	max.mould plate dimension(W*H)	mm	280 *300
	最大模板尺寸	mm	280 *300
	thickness of mould 模具厚度	mm	220
	clamping force	KN	160
	mould opening stroke开模行程	mm	125
r	空压机压力air compressor	M3 /Mpa	≥1.65/3.0*1set
r	功率air pressure for blowing	KW	48
	冷水机Water chiller	HP	5HP
	功率power	KW	1.5/10
	电压voltage/frequency	V/HZ	380/240/110/50-60 (3-phase)
	主机外形尺寸main machine(LWH)	M	2.51.952.2
	上料机	M	1.91.22.6
	重量main machine weight	T	2.8

1, Specifications of L-BS514(4-cavity):
1.1, Main machine dimension:4200(L)1900(W)2200(H)mm;
1.2, Theoretical output: 4000bph(500ml)
1.3, The main structure is made of #63 channel steel, welded by A3 folding, the surface (blue as basic color) is treated with plastic ejection. the whole structure is delicate and durable.
1.4, Stretch cylinder and pneumatic components adopt SMC brand，PLC is from Taiwan Delta.
1.5, Conveyor system adopts #45 steel, the surface is galvanized.
1.6, Automatic preform-feeding for conveyor, it is easy to operate by only putting a certain quantities of preforms inside the feeding bucket. The movement of feeding,heating,blowing and finished bottle transferring is done automatically.
1.7, Preforms are transferred to the heater through rotating and passing-one-by-one to ensure being heated evenly.
